Anodeless Risers
BigGuy® Riser options are available for a variety of residential and commercial gas applications. Risers offer a safe and simple method for connecting and transitioning from the PE pipe below the ground to the above ground piping system.
FEATURES:
- Epoxy Coated Steel Casing is electrostatic bonded coating providing long-term underground corrosion protection.
- Casing is TIG welded to adapter for a stronger and higher quality welder joint.
- Every part is leak tested.
- Meets or exceeds all ASTM 02513 Category 1 and NFPA-58 requirements.
- Available with Con-Stab coupling attached.
Anodeless Risers
| Item No. | Pipe Size MPT | Vertical Dimension | Con-Stab Coupling |
|---|---|---|---|
| A3434 | 3/4" | 24" | No |
| A3430 | 3/4" | 30" | No |
| A3436 | 3/4" | 36" | No |
| A124 | 1" | 24" | No |
| A130 | 1" | 30" | No |
| A11430 | 1-1/4" | 30" | No |
| A11436 | 1-1/4" | 36" | No |
| A11230 | 1-1/2" | 30" | No |
| A11236 | 1-1/2" | 36" | No |
| A230 | 2" | 30" | No |
| A236 | 2" | 36" | No |
| A3430C | 3/4" | 30" | Yes |
| A130C | 1" | 30" | Yes |
| A11430C | 1-1/4" | 30" | Yes |
| A11236C | 1-1/2" | 36" | Yes |
| Available in additional sizes. |
